Product Specification
Model: PI - 2030 FR
Print Area: 200 × 300 mm
Print Speed: 1000 pcs/hour
Power: 110/220V 50W
Machine Size: 97 × 72 × 85 cm
Weight: 125 kg

Range of Application:

This screen print machine mainly used the silica gel key mobile optic screen print. It use the front back slide table to let the product print and pick and place not disturb, which enhance the efficiency and Ave labor. It can compose the product line in small workshop or small place.

Technical Parameter
Microcomputer system Action option: fully automatic / semi automatic / manual
Auto 4-digit built in counter for counting printing quantity Start up method: panel / foot switches
The transversal stroke can be adjusted, spacing by Korea electronic switch Scrapper pressure controller: by pressure regulating valve
Aluminium body metal coating surface Vertical driving style: pneumatic
The angle of scraper and ink covering blades can be adjusted randomly Transversal driving style: pneumatic
Scraper constant pressure device to make sure pressure is steady Maximum printing area: 200 × 300 mm
Can regulate screen work table back and forth, right and left Transversal stroke: 400 mm
Can regulate screen frame back and forth, right and left Lift right stroke: 400 mm
With the T-slot work table easy install fixture and can install Vacuum table Vertical stroke: 80 mm
Installing CEC oil buffer avoid printing shock Work piece max high: 100 mm
Running fast, steady and lower noise Ink scraper size: 9 × 50 mm
Print head quick lifting device, Use Taiwan pneumatic element Max frame size: 400 × 600 mm
